- Tests on cement: Determination of Fineness modulus by sieve analysis and/or by air permeability method, standard consistency, setting times, soundness, specific gravity, compressive strength.
- Tests on Aggregates: Sieve analysis of fine aggregate and coarse aggregates for determination of fineness modulus and grain size distribution, determination of water absorption and specific gravity of fine aggregate and coarse aggregates, bulking of sand, crushing value of coarse aggregates.
- Tests on Steel: Tensile strength of mild steel and HYSD Bars.
- Tests on Bricks: Determination of shape, size and Water absorption of Bricks.
- Tests on Concrete:Compressive strength, flexural strength and split tensile strength of concrete.
- ACADEMICS
- >
- DEPARTMENTS
- >
- CIVIL ENGINEERING
- >
- LABORATORIES
LABORATORIES
MATERIAL TESTING LABORATORY
Experiment List
EQUIPMENT LIST
| SL NO | ITEMS |
| 1 | SIEVE SET |
| 2 | COMPRESSION TESTING MACHINE |
| 3 | CUBE MOULD(70.6MM) |
| 4 | WEIGHING BALANCE(30KG) |
| 5 | TROWEI |
| 6 | TRAY |
| 7 | LE CHATELIER APPARATUS |
| 8 | LE CHATELIER FLASK |
| 9 | MEASURING CYLINDER(500ml) |
| 10 | MEASURING CYLINDER(250ml) |
| 11 | OVEN |
| 12 | SPECIFIC GRAVITY BOTTOL |
| 13 | STOP WATCH |
| 14 | VICAT APPARATUS |
| 15 | WATER BATH |
SURVEY FIELD WORK
Experiment list
- Testing of chain measurement of correct length of the line
- Traversing by chain surveying
- Traversing by compass survey
- Intersection method of plane table survey
- Traversing by plane table
- Use of dumpy level and fly leveling
- longitudinal section and cross section of road
- Contouring
- Measurement of horizontal and vertical angle by theodolite
EQUIPMENT LIST
| SL. NO. | NAME OF THE EQUIPMENT | |
| 01 | Chain ,30 m length | |
| 02 | Tape ,30 m length | |
| 03 | Arrow pin | |
| 04 | Ranging rod | |
| 05 | Total station | |
| 06 | Theodolite | |
| 07 | Dumpy level | |
| 08 | Prismatic compass | |
| 09 | Plane table with all accessories | |
| 10 | Clinometers | |
| 11 | Leveling staff | |
| 12 | Auto level | |
| 13 | Total Station | |
| 14 | GPS | |
| 15 | DGPS |
GEOTECHNICAL LABORATARY
Experiment list
01. Determination of specific gravity of soil grains
02. Determination of grain size distribution of soil
a) Sieve test
b) Hydrometer
03. Determination of Atterberg limits of soil
a) Liquid limit
b) Plastic limit
c) Shrinkage limit of soil
04. Measurement of soil compaction in field
a) Core cutter method
b) Sand replacement method
05. Determination of Density – water content relationship of soil
a) Proctor compaction test
b) Modified proctor compaction test
c) Use of proctor penetration needle
06. Determination of relative density of granular soil
07. Determination of shear strength parameter of soil
a) Shear box test
b) Tri-axial compression test
c) Unconfind compression test
d) Vane shear test
08. Determination of consolidation characteristics of soil using fixed ring odometer
09. Determination of California Bearing ratio ( CBR ) of soaked and un-soaked soil specimens
10. Determination of coefficient of permeability of soil
a) Constant head permeameter
b) Falling head permeameter
EQUIPMENT LIST
| SL NO | ITEMS |
| 1 | CONSOLIDATION APPARATUS |
| 2 | DIRECT SHEAR TEST APPARATUS |
| 3 | FIELD DENSITY CORE CUTTER |
| 4 | HYDROMETER |
| 5 | HAND OPERATED EXTRACTOR APPARATUS |
| 6 | LIQUID LIMIT DEVICE APPARATUS |
| 7 | PERMEABILITY APPARATUS |
| 8 | OVER HEAD TANK APPARATUS |
| 9 | PYCNOMETER |
| 10 | PLASTIC LIMIT APPARATUS |
| 11 | RELATIVE DENSITY APPARATUS |
| 12 | SAND POURING CYLINDER APPARATUS |
| 13 | SHRINKAGE LIMIT APPARATUS |
| 14 | SHIVE SHAKER APPARATUS |
| 15 | TRIAXIAL APPARATUS |
| 16 | UNCONFINED COMPRESSION APPARATUS |
| 17 | VANE SHEAR APPARATUS APPARATUS |
TRANSPORTATION ENGINEERING LAB.
Experiment list
- Determination of aggregate crushing value.
- Determination of Los Angeles abrasion value of aggregates.
- Determination of aggregate impact value.
- Determination of penetration value of bitumen.
- Determination of softening point value of bitumen.
- Determination of ductility value of bitumen.
- Determination of flash and fire point of bitumen.
- Determination of specific gravity of bitumen.
- Determination of stripping value of aggregate.
- Determination of flakiness index and elongation index of coarse aggregate.
- Determination of specific gravity and water absorption of coarse aggregate.
- Determination of CBR of soil subgrade.
- Design of GSB and WMM
- Marshal method of mix design.
EQUIPMENT LIST
| SL NO | ITEMS |
| 1 | AGGREGATE CROSSING VALUE APPARATUS |
| 2 | AGGREGATE IMPACT TEST APPARATUS |
| 3 | CBR APPARATUS |
| 4 | DUCTILITY TESTING MACHINE |
| 5 | DEVAL ATTRITION TESTING MACHINE |
| 6 | DENSITY BASKET WITH HANDLE |
| 7 | FLASH AND FIRE POINT APPARATUS |
| 8 | FILM STRIPPING APPARATUS |
| 9 | LOSS ANGELES ABRASION TEST MACHINE |
| 10 | LENGTH GAUGE |
| 11 | MARSALL STABILITY TEST APPARATUS |
| 12 | RING AND BALL APPARATUS |
| 13 | THICKNESS GAUGE |
| 14 | THERMOMETER |
| 15 | UNIVERSAL PENETROMETER |
CONCRETE AND STRUCTURAL LAB.
Experiment list
01. Workability test of concrete
a) Slump test
b) Compaction factor test
c) Flow table test
02. Cube test of concrete
03. Cylinder test for concrete.
04. Split tensile strength of concrete.
05. Prism Test for determining modulus of rupture of concrete.
06. Design of concrete Mix.
07. Failure of RC beam in bending and shear.
EQUIPMENT LIST
| SL NO | NAME OF THE EQUIPMENT | |
| 01 | CTM machine | |
| 02 | Flexural testing machine | |
| 03 | Cube mould ( 150 X150X150 ) mm | |
| 04 | Cube mould ( 70.6X 70.6X70.6 ) mm | |
| 05 | Cylinder mould | |
| 06 | Slump test apparatus | |
| 07 | Compaction factor apparatus | |
| 08 | Flow table |
HYDRAULICS LAB
Experiment list
- Proof of Bernoulli’s theorem.
- Friction flow through pipes.
- Determination of Reynolds number.
- Determination of metacentric height.
- Determination of coefficient of discharge for v-notch.
- Determination of coefficient of discharge for venturimeter.
- Impact of jet.
- Flow through orifice.
- Proof of stokes law.
- Work done by pelton wheel turbine.
- Efficiency of Francis turbine.
- Discharge through centrifugal pump.
EQUIPMENT LIST
| SL NO | NAME OF THE EQUIPMENT | |
| 01 | Impact of jet on vane apparatus | |
| 02 | Reciprocating pump test rig | |
| 03 | Centrifugal pump test rig | |
| 04 | Pelton wheel turbine test rig | |
| 05 | Francis turbine test rig | |
| 06 | Kaplan turbine test rig |
CAD LAB
Experiment list
- Introduction to MATLAB and Excel
- Plotting of Shear force and bending moment diagram of beam using MATLAB
- Drawing of Shear force and bending moment diagram of frames using MATLAB
- Plotting of Shear force and bending moment diagram of arches using MATLAB
- Calculation and plotting of ILDs of beam using MATLAB
- Calculation and plotting of ILDs of frames using MATLAB
- Calculation and plotting of ILDs of arches using MATLAB
- Plotting of stress contours using MATLAB
- Introduction to Graphic Software: Basic commands, plotting of graphs and data analysis.
